Date:2015-12-10

4400mAh 3.2V 35C Discharge A123 32113 LiFePo4 High Drain Battery Cell for RC


32113 type LiFePo4 battery cells are mostly applied to high drain battery pack assembly for car, motorcycle, RC airplane and so forth.

Specifications

Item Specifications
Nominal Voltage 3.2V

Capacity

4400mAh

Charging Voltage 3.60V
Maximum discharge current 35C
Discharge cut-off voltage
End of discharge

2V
(2V discharge cut-off is better in cycle life )

Charge cut-off voltage
End of charge

3.65V (max.)

Internal resistance 4mΩ
Cell dimension

Diameter:  31±0.2mm
Height:  113±2.0mm



Features

32113 type LiFePo4 battery cells are mostly applied to high drain battery pack assembly for car, motorcycle, RC airplane and so forth.
The 32113 battery mafacturer is A123 Systems from USA.

With LiFePo4 as the materials, it has high capacity, high energy-density and high performance discharge (35C).
