Date:2019-02-26

Panasonic NCR2070C 3.7V 3620mAh 30A High Drain Battery for Battery Pack


With very high capacity 3500mAh and high discharge current 30A, NCR2070C is a good model forlithium ion battery packs which requires high working current.



Nominal Voltage

3.6V

Rated Capacity

3475mAh

Minimum Capacity

3500mAh

Typical Capacity

3620mAh

Charge Voltage

4.20±0.05V

Charge Method

CC-CV

Continuous Maximum Charge

Standard: 2450mA

Charge Time

Standard Charge: 180min.

Max. Discharge current

30A

Discharge cut-off voltage
End of discharge

2.5V

Internal resistance

10mΩ

Weight

62.0g max.

Dimension

Height:  70.3 mm (max.)

Diameter:  20.4 mm (max.)

Ambient temperature

Charge : 10 to 45
Discharge: -20 to 60
Storage: -20 to 50


Application: For electronic devices that require high performance and capacity.
Notice: NCR2070C is a good model for high performance battery packs. EVVA is able to provide customized BMS and assemble battery packs by using this model for you.
Waning: This cell can only be used for battery pack assembling. Any improper use such as removing cells from battery packs is not recommended.
