1S2P 553450 3.7V 2300mAh Li-ion Rechargeable Prismatic Battery with PCM


High end prismatic Li-ion rechargeable battery OEM
Item Specification
Model SC2-553450
Nominal Capacity 2050mAh
Cells Model Sanyo UF553450Z, made in Japan
Nominal Voltage 3.7V
Charging Voltage 4.2V
Standard Charge Current 0.5C
Standard Discharge Current 0.2C
Maximum Discharge Current 1.0C for continuous
2.0C for peak
End Voltage of Discharge 2.75V
Cycle Life ≥500 cycles
Weight 49g max.
Size  54.2mm*34mm*11mm approximate
OEM Acceptable
Made of 2pcs of Sanyo 553450 Li-ion rechargeable cell with PCB protection circuit.
Well protected gainst over charge, over discharge, short circuit and over current
Applicable to a variety of portable electronic devices or medical equipments
OEM orders available
