Protected 103450 Li-ion Prismatic Battery Wires Out 3.7V 2300mAh


Protected Sanyo UR103450F 2300mAh Li-ion rechargeable battery with wires, OEM available
Item Specification
Model 103450-1S1P
Nominal Capacity 2300mAh
Nominal Voltage 3.7V
Charging Voltage 4.2V
Standard Charge Current 0.5C
 Discharge Current 0.2C for continuous
0.5C for peak
End Voltage of Discharge 2.5V
Cycle Life ≥300 cycles
Weight 45g max.
Size  52.10mm*34.55mm*10.90mm approx.
Customized Acceptable
Made of 1pcs of Sanyo UR103450F Li-ion rechargeable cell with PCB protection circuit.
Well protected gainst over charge, over discharge, short circuit and over current
Applicable to a variety of portable electronic devices
OEM orders available
