13.2V 12.5Ah A123 ANR26650 4S5P LiFePo4 Battery Pack for Electric vehicle


Use original A123 high drain cell,and weld with copper plate to allow higher current passing through.
Item Specification
Model ANR26650-4S5P
Nominal Capacity 12500mAh
Nominal Voltage 13.2V
Cell model Original A123 ANR26650M1B LiFePo4 cell, A Grade
Max. Continuous Discharge  250A
Pulse Discharge 400A
Welding Material Pure copper and nickel plate
Connecotor Type Customized
Weight 1550g approx.
Dimension 270mm(L)*55mm(W)*68mm(H) approx.
Applicable to  EV(electric vehicle), electric motorcycle ect.
