18500 2S1P 7.4V Li-ion Rechargeable Battery with PCB 2000mAh

Lithium ion battery pack composed of 2pcs of 18500 cells, PCM, NTC and connector.
Item Specification
Model EV1850P-2S1P
Nominal Capacity 2000mAh (customized)
Nominal Voltage 7.4V
Charging Voltage 8.4V
Standard Charge Current 0.5C
Rapid Charge Current 1C
Standard Discharge Current 0.2C
End Voltage of Discharge 5V
PCB Function Protecting battery from over-charge, over-discharge,
short circuit, over temperature, etc.
Cycle Life ≥500 cycles
Weight 80g max
Dimension 100mm(H)*21mm(D) approximate
OEM Acceptable
Made of 2pcs of 18500 Li-ion rechargeable cells with PCB protection circuit.
Applicable to a variety of portable electronic devices

OEM orders available
