18650 10S3P 36V Long Lithium ion Battery Pack for Electric Kick Scooter


Selecting quality cells from high-end brands and build with our self-designed BMS to assure you a wonderful and safe journey
Item Specification
Model EV18650-10S3P
Nominal Voltage 36V (customized)
Nominal Capacity 7.8Ah/9Ah//10.5Ah/15Ah
Charge Voltage 42V
Max. Charge Current 5A
Max. Continuous Discharge Current 20A~25A
Discharge Cut-off Voltage 25V
BMS Safety Function Cell balancing, over-charge, over-discharge,
over temperature, short-circuit protection
Cycle Life 80% capacity remaining after 1000 cycles
Weight (max.) 1.6kg
Dimension(max.) (L)556mm*(W)66.00mm*(T)29.45mm
Operating Temperature Charge: 0~45℃
Discahrge: -20~60℃
