18650 21700 10S4P 36V Lithium ion Battery Pack


Custom high-end Lithium ion Solutions by selecting the best cells, self-designed smart BMS, UL approved cabels and other components.
Item Specification
Model 10S4P
Nominal Voltage 36V (customized)
Nominal Capacity 20Ah (customized)
Charge Voltage 42V
Max. Charge Current 5A
Max. Continuous Discharge Current 20A~30A
Discharge Cut-off Voltage 25V
BMS Safety Function Cell balancing, over-charge, over-discharge,
over temperature, short-circuit protection
Cycle Life 80% capacity remaining after 1000 cycles
Weight (max.) 2.9kg
Dimension(max.) (L)220mm*(W)86mm*(T)75mm approx.
Operating Temperature Charge: 0~45℃
Discahrge: -20~60℃
