Date:2016-04-09

10A High Drain-EVVA Protected 18650 3400mAh Li-ion Rechargeable Battery


1. Cell Origin: Japan 2. IC Brand: SEIKO 3. NO.of MOSFETs: 3 4. Continuous discharge: 10A

Specifications



Type

EVVA Protected 18650 3400mAh 10A li-ion battery

Supplier

EVVA TECHNOLOGY CO.,LIMITED

Cell

Sanyo NCR18650BL high drain cell

Nominal voltage

3.7V

Nominal capacity

3400mAh

discharge at 0.2C mA

Stanard Charge voltage

4.20V ( Full Charged Voltage )

Standard Charge current

1620mA

Charge Time(Std.)

4hours

Discharge cut-off voltage

2.50V

PCB Protection trip current

about 10A

Operating environment

Charging, 0°C ~ 45°C ;  65±20%RH

Discharging, -20°C~60°C ;  65±20%RH

Storage environment

-20°C~60°C; Less than 1 month

-20°C~60°C; Less than 3 months

Cell Weight )

50g max.

Cell Dimension

(L)68.90mm*(D)18.60mm
