Specifications
|
Product Name |
26650 Protected lithium battery 4000mAh |
|
Supplier |
EVVA TECHNOLOGY CO.,LIMITED |
|
Cell |
King Kong ICR26650E 4000mAh cell |
|
Nominal voltage |
3.7V |
|
Nominal capacity |
4000mAh discharge at 0.2C mA |
|
Minimum capacity |
3950mAh |
|
Stanard Charge voltage |
4.20V ( Full Charged Voltage ) |
|
Standard Charge current |
2000mA |
|
Charge Time(Std.) |
3 hours |
|
Discharge cut-off voltage |
2.75V |
|
Standard Discharge current |
800mA |
|
Standard Discharge cut off current |
30mA |
|
PCB Protection trip current |
about 10A |
|
Operating environment |
Charging, 0°C ~ 45°C ; 65±20%RH |
|
Discharging, -20°C~60°C ; 65±20%RH |
|
|
Storage environment |
-20°C~60°C; Less than 1 month |
|
-20°C~60°C; Less than 3 months |
|
|
Cell Weight ) |
92g approx. |
|
Cell Dimension |
(L)70.20mm*(D)26.50mm max. |
Features
1. High quality approved: use quality cells with real capacity
2. Safety guaranteed: with all necessary protection---Seiko IC chip and AO Mosfets on the PCB to protect battery from over charge, over discharge, short circuit, over temperature and low temperature
3. Nice look: quality shrink wrap (black or clear) and gold-plated protection circuit module
4. OEM battery is available
