Date:2016-04-16

3.7V 700mAh Protcted 16340 Lithium ion Rechargeable Battery


Protected 16340 700mAh li-ion battery for flashlight. In-built Seiko IC and MOSFETs to protect battery from over charge, over discharge and short circuit. Gold-coated PCB can ensure a better conductivity.

Specifications

Type

16340 lithium rechargeable battery protected

Supplier

 EVVA TECHNOLOGY CO.,LIMITED

Cell

DLG ICR16340 3.7V 700mAh

Nominal voltage

3.7V

Nominal capacity

700mAh



discharge at 0.2C mA

Minimal capacity

2700mAh

Stanard Charge voltage

4.30V ( Full Charged Voltage )

Standard Charge current

350mA

Charge Time(Std.)

3 hours

Discharge cut-off voltage

2.75V

Standard Discharge current

140mA

Standard Discharge cut-off current

30mA

PCB protection trip current

about 5A

Storage environment

-20°C~60°C; Less than 1 month

-20°C~60°C; Less than 3 months

Cell Weight )

20 g max.

Cell Dimension (approx.)

(L)35.60mm*(D)16.70mm
