Date:2020-03-04

LG INR18650MJ1 18650 3500mAh 10A High Power Battery Cell


Light weight and high performance with 10A continuous discharge at the most capacity



Item Specifications
Nominal Voltage 3.635V
Nominal Capacity

3500mAh std.

3400mAh min.

Standard charge

Constant Current: 0.5C (1700mA)

Constant voltage : 4.2V

End current(Cut off) : 50mA

Max. Charge Current 1.0 C (3400mA)
Max. Charge Voltage 4.20 ± 0.05 V
Standard Discharge

Constant Current: 0.2C (680mA)

End current(Cut off) : 2.5V

Max. continuous discharge

10A

Discharge cut-off voltage
End of discharge
2.5V
( 2.5V discharge cut-off is better in cycle life )
Cell weight

49.0g max.

Cell dimension

Height :  65.0  ±0.2mm max.
Diameter :   18.4 +0.1 / -0.3 mm

Operating temperature
(surface temperature)

 Charge : 0 to 45
(recommended recharge release < 45°C)
Discharge: -20 to 60
(recommended re-discharge release < 60°C)

Storage temperature
(Recovery 90% after storage)

1 year -20~20°C
3 months -20~45°C
1 month -20~60°C

Applicable to most elcetronic devices, especially for thoses that require high discharge current such as e-bike and drill, e-scooters and power tools.

Notice: This cell is not for sale. The cell is used for battery pack assembling, and it needs to add a protection circuit module before use.
EVVA is capable of assembling different battery packs by combining these high-end battery cells and self-developed BMS based on our professional rich skills.
Welcome OEM orders.
