1S1P 18650 3.7V Li-ion Rechargeable Battery with NTC Wires Out 2600mAh wires out

Built-in NTC on PCM for temperature protection.
Item Specification
Model SIN18650-26
Nominal Capacity 2600mAh (customized)
Minimum Capacity 2500mAh
Nominal Voltage 3.6V
Open Circuit Voltage  3.5~3.8V
Charging Voltage 4.2V (3 hours)
Standard Charge Current 0.5C (1300mA)
Standard Discharge Current 0.2C (520mA)
Max. Discharge Current 2C (5200mA)
End Voltage of Discharge 2.75V
PCB Function Protecting battery from over-charge, over-discharge,
short circuit, over temperature, etc.
Connector JST-XH-3P
Cycle Life ≥500 cycles
Weight 50g max
Dimension 66.5mm(H)*22mm(D) approximate
OEM Acceptable
Made of 1pcs of 18650 high quality batttery cell with protection circuit module.
Applicable to a wide range of electronic devices.
OEM available on capacity, wires, connector, logo, color, etc.
