Specifications
| Item | Specification |
| Nominal Capacity | 3100mAh(0.2C, 2.50V discharge) |
| Minimum Capacity | 2950mAh (0.2C, 2.50V discharge) |
| Charging Voltage | 4.2±0.05V |
| Nominal Voltage | 3.6V |
| Charging Method | CC-CV (constant voltage with limited current) |
| Charging Current | Standard charge: 1700mAh, Rapid charge: 3100mAh |
| Charging Time | Standard charge: 3 hours, Rapid charge: 2.5 hours |
|
Max. Charge Current |
3100mAh (ambient temperature 25°C) |
| Max. Discharge Current | 600mAh (ambient temperature 25°C) |
| Discharge Cut-off Voltage | 2.50V |
| Cell Weight | 45.5g |
| Cell Dimension | Height: 65.20mm max. Diameter: 18.60mm max. |
| Operating Temperature | Charge: 0 to 45 °C Discharge:-20 to 60°C |
