Specifications
| Item | Specification | Note |
| Model | US18650VTC3 lithium high power battery |
|
| Nominal capacity | 1600mAh |
Discharge at 0 2ItA, 2.5V cut-off after Standard charge |
| Rated capacity | 1500mAh |
Discharge at 0 2ItA, 2.5V cut-off after Standard charge |
| Nominal voltage | 3.7V | |
| Charge voltage |
4.20±0.05V |
|
| Cut-off voltage | 2.5V | |
| Max. charge voltage | 4.25V | |
| Continuous maximum charge current | 10A | |
| Continuous maximum discharge current | 30A | |
| Weight | 45.1±1.5g | |
| Allowable environment temperature |
Charge: 0 to +45degC Discharge: -20 to +60degC |
CC-CV 4.20V±0.005V, 1.5A, 2.5hrs |
This kindly of high power cell used Spinel chemistry , The Spinel chemistry is what makes the cells so good. They are not the typical LiCo technology.
Applications
Power tools, Robotics, Electronic cigarette, Electric bike and other electronic devices
Cell Show
