Date:2015-11-30

LG 18650HB6 1500mAh 30A High Power Battery Cell

Suitable for most elcetronic devices, especially power tools such as e-bike and drill, e-cigarettes.

Specifications

NO.	Item	Specifications
1	Nominal Voltage	3.65V
2	Nominal Capacity	1500mAh std. 1400mAh min.
3	Standard charge	Constant Current: 750mA Constant voltage : 4.2V End current(Cut off) : 50mA
4	Max. Charge Current	Constant current: 4000mA End condition (cut-off): 100mA
5	Max. Charge Voltage	4.25 V
6	Standard Discharge	Constant Current: 300mA End current(Cut off) : 2.0V
7	Max. continuous discharge	30A
8	Discharge cut-off voltage End of discharge	2.5V ( 2.5V discharge cut-off is better in cycle life )
9	Cell weight	48.0g max.
10	Cell dimension	Height : 65.2mm max. Diameter : 18.4 mm max.
11	Operating temperature (surface temperature)	Charge : 0 to 50 Discharge: -20 to 75
12	Storage temperature (Recovery 90% after storage)	1 year -20~20°C 3 months -20~45°C 1 month -20~60°C

Applications

Suitable for most elcetronic devices, especially power tools such as e-bike and drill, e-cigarettes.

For more information please feel free to contact us.
