6S1P 18650 22.2V Li-ion Battery Pack 3400mAh with Fuel Gauge SMbus
Battery pack can support System Management Bus (SMBus) protocol which can show the state of charge, battery temperature, cell voltages, current drawn from the cells, failure messages, charging status
|
Item |
Specification |
|
Model |
SM18650-6S1P-34 |
|
Nominal Capacity |
3400mAh |
|
Nominal Voltage |
22.2V |
|
Charging Voltage |
25.2V |
|
Charge Current |
0.2C std.
0.5C rapid |
|
Standrad Discharge Current |
0.2C |
|
Maximum Discharge Current |
1.0C |
|
End Voltage of Discharge |
15V |
|
smBUS Protocol Function |
Communication |
|
Protection Circuit Module Function |
Over charge
Over discharge
Over current
Short circuit
Over temperature
Low temperature |
|
Cycle Life |
>500cycles |
|
Weight |
310g max. |
|
Size |
110mm*67.5mm*23mm |
|
Customized |
Acceptable |
Made of 6pcs of Panasonic NCR18650B 3400mAh cylindrical 18650 cell with PCM for full protection.
Applicable to RC toy (cars and airplanes), robots and other electronic portable devices.
Battery pack support System Management Bus (SMBus) protocol.
-
State of charge
-
Battery temperature
-
Cell voltage
-
Current drawn from the cells
-
Failure messages
-
Charging status
-
Discharging statusk
