Date:2020-03-04
2S2P Lithium ion 18500 Rechargeable Battery Wires Out 7.4V 2000mAh
18500 2S1P 7.4V 2000mAh Li-ion rechargeable battery pack
|
Item |
Specification |
|
Model |
EV18500-2S1P |
|
Nominal Capacity |
2050mAh |
|
Nominal Voltage |
7.4V |
|
Charging Voltage |
8.4V |
|
Rapid Charge Current |
1.0C |
|
Maximum Discharge Current |
1.0C for continuous
2.0C for peak |
|
End Voltage of Discharge |
5V |
|
Cycle Life |
≥300 cycles |
|
Weight |
70g max. |
|
Size |
52.20mm(H)*36.80mm(W)*19.00mm(T) approximate |
|
OEM |
Acceptable |
Made of 2pcs of 18500 Li-ion rechargeable cell with PCB protection circuit.
Away from over charge, over discharge, short circuit and over current
Applicable to a variety of portable electronic devices
OEM orders available
