| Item | Specification |
| Model | SIN18650-26 |
| Nominal Capacity | 2600mAh (customized) |
| Minimum Capacity | 2500mAh |
| Nominal Voltage | 3.6V |
| Open Circuit Voltage | 3.5~3.8V |
| Charging Voltage | 4.2V (3 hours) |
| Standard Charge Current | 0.5C (1300mA) |
| Standard Discharge Current | 0.2C (520mA) |
| Max. Discharge Current | 2C (5200mA) |
| End Voltage of Discharge | 2.75V |
| PCB Function |
Protecting battery from over-charge, over-discharge, short circuit, over temperature, etc. |
| Connector | JST-XH-3P |
| Cycle Life | ≥500 cycles |
| Weight | 50g max |
| Dimension | 66.5mm(H)*22mm(D) approximate |
| OEM | Acceptable |
