2S2P 18650 7.2V Li-ion Battery Pack with Connector 6800mAh


Use A Grade cells directly from Japan and self-designed high-end PCM for a high quality battery pack
Item Specification
Model NCR18650B-2S2P
Nominal Capacity 6800mAh (customized)
Cell Origin Japan
Nominal Voltage 7.2V
Charging Voltage 8.4V
Standard Charge Current 0.5C
Rapid Charge Current 1C
Standard Discharge Current 0.2C
End Voltage of Discharge 5V
PCB Function Protecting battery from over-charge, over-discharge,
short circuit, over temperature, etc.
Cycle Life ≥500 cycles
Weight 200g max
Dimension 38mm(L)*38mm(W)*68mm(H) approximate
OEM Acceptable
Made of 2pcs of 18500 Li-ion rechargeable cell with PCB protection circuit.
Applicable to a variety of portable electronic devices
OEM available for connector, wire length, color, capacity, voltage, logo etc.
