| Part No. | EV1865-15S |
| Cell origin | Selected A Grade Samsung or Murata power cells |
| Nominal Capacity | 6000mAh~10000mAh (customized) |
| Nominal Voltage | 54V |
| Standard Charge Voltage | 63V |
| Standard Charge Current | 2A |
| Max. Charge Current | 1C |
| NTC built-in | Yes |
| Connector | XT-60 |
| Balancing function | Yes |
| Max. Continuous Discharge Current | 60A (with temperature cut) |
| Discharge Cut-off Voltage | 41.25V |
| Dimension | (L)180.00mm*(W)135.00*(H)40.00mm approx. |
| Weight | 1.5kg max. |
| Operating Temperature |
Charge: 0~45dgC Discharge: -20~60dgC |
