| Item | Specification |
| Cell Type | Lithium iron Phosphate |
| Nominal Voltage | 3.2V |
| Nominal Capacity | 40.0Ah |
| AC-impedance | ≤1.0mΩ |
| Dimension | 149mm*133.5mm*28mm max. |
| Weight | 1010±20g |
| Max. Charge Current |
3C (120A) continuous 4C (160A) for 30s |
| Full charge Voltage | 3.65V |
| Max. Discharge Current |
5C (200A) continuous 6C (240A) for 30s |
| Discharge Cut-off Voltage | 2.0V (1C) |
| Operating Temperature |
Charge: 0~45℃ Discharge: -20~60℃ |
| Storage Temperature |
1 month: -40~45℃ 6 months: -20~35℃ |
