Specifications
|
Type |
3.7V 3200mAh 18650 lithium battery protected |
|
Supplier |
EVVA TECHNOLOGY CO.,LIMITED |
|
Cell |
Panasonic NCR18650BD high drain cell |
|
Nominal voltage |
3.7V |
|
Nominal capacity |
3200mAh discharge at 0.2C mA |
|
Stanard Charge voltage |
4.20V ( Full Charged Voltage ) |
|
Standard Charge current |
1600mA |
|
Charge Time(Std.) |
3 hours |
|
Discharge cut-off voltage |
2.50V |
|
Max. Continuous Discharge Current |
10A |
|
Standard Discharge cut off current |
30mA |
|
PCB Protection trip current |
10A |
|
Operating environment |
Charging, 0°C ~ 45°C ; 65±20%RH |
|
Discharging, -20°C~60°C ; 65±20%RH |
|
|
Storage environment |
-20°C~60°C; Less than 1 month |
|
-20°C~60°C; Less than 3 months |
|
|
Cell Weight ) |
50g max. |
|
Cell Dimension |
(L)68.90mm*(D)18.60mm |
Use original Panasonic NCR18650BD 3200mAh high drain cells to ensure high performance
With gold-coated protection circuit board: SEIKO IC, two or three Mosfets
