Sony US18650VTC5 2600mAh 30A High Drain Battery Cell Sony VTC5
Item Specifications Nominal Voltage 3.6V Capacity Typical: 2500mAh Minumum: 2600mAh Charging Voltage 4.20V Continuous maximum dischargecurrent 30A(at 25C) Maximum discharge current 60A Discharge cut-off voltage End of discharge 2.5V (2.5V d
|
Item |
Specifications |
|
Nominal Voltage |
3.6V |
|
Capacity
|
Typical: 2500mAh
Minumum: 2600mAh
|
|
Charging Voltage |
4.20V |
|
Continuous maximum discharge current |
30A(at 25°C) |
|
Maximum discharge current |
60A |
Discharge cut-off voltage
End of discharge |
2.5V
(2.5V discharge cut-off is better in cycle life ) |
|
Continuous Maximum Charge Current |
12A |
|
Cell weight |
44.30g Average |
|
Cell dimension |
18.35*65.20mm |
Operating temperature
(surface temperature) |
Charge : 0 to 50
(recommended recharge release < 45°C)
Discharge: -20 to 75
(recommended re-discharge release < 60°C)
|
Applicable for high performance electronic devices such as e-bike, e-scooter, electric motorcycle, electric automobile, diving light, power tools, etc.
Cells can only be used for battery pack assembling.
OEM battery pack orders are acceptable in EVVA.
