Model |
EV1865H-35 |
|
Cell Origin |
Panasonic(Sanyo) NCR18650GA, made in Japan |
|
Nominal voltage |
3.7V |
|
Nominal capacity |
3500mAh discharge at 0.2C mA |
|
Stanard Charge voltage |
4.20V ( Full Charged Voltage ) |
|
Standard Charge current |
1000mA |
|
Charge Time(Std.) |
4hours |
|
Discharge cut-off voltage |
2.50V |
|
PCB Protection trip current |
about 10A |
|
Operating environment |
Charging, 0°C ~ 45°C ; 65±20%RH |
|
Discharging, -20°C~60°C ; 65±20%RH |
|
|
Storage environment |
-20°C~60°C; Less than 1 month |
|
-20°C~60°C; Less than 3 months |
|
|
Cell Weight ) |
50g max. |
|
Cell Dimension |
(L)68.90mm*(D)18.60mm |
Use high-end lithium ion cell made in Japan, quality guaranteed
Built-in safety circuitry: SEIKO IC Chip, three MOS (high performance), gold-coated surface
