Item | Specification |
Nominal Capacity | 3400mAh(0.2C, 2.50V discharge) |
Minimum Capacity | 3250mAh (0.2C, 2.50V discharge) |
Charging Voltage | 4.2±0.05V |
Nominal Voltage | 3.6V |
Charging Method | CC-CV (constant voltage with limited current) |
Charging Current | Standard charge: 1700mAh, Rapid charge: 3400mAh |
Charging Time | Standard charge: 3 hours, Rapid charge: 2.5 hours |
Max. Charge Current |
3400mAh (ambient temperature 25°C) |
Max. Discharge Current | 6800mAh (ambient temperature 25°C) |
Discharge Cut-off Voltage | 2.50V |
Cell Weight | 48g max. |
Cell Dimension | Height: 65.00mm max. Diameter: 18.25mm max. |
Operating Temperature | Charge: 0 to 45 °C Discharge:-20 to 60°C |
Application : Laptop, Power Bank, ESS(Energy Storage System), UPS(Uninterruptible Power Supply)
