Specifications
| Item | Condition / Note | Specification |
| Capacity | Std. charge / discharge |
Nominal: 2200mAh Minimum:2100mAh |
| Nominal Voltage | Average of Std. Discharge | 3.6V |
| Standard Charge |
Constant current |
0.5C(1,050mA) |
|
Constant voltage |
4.20V | |
| End current(Cut off) | 50mA | |
| Max. Charge Voltage | 4.20V | |
| Max. Charge Current | 1C (2,100mA) | |
|
Standard Discharge |
Constant Current: 0.2C (750mA) End Voltage (Cut-off): 2.5V |
|
|
Max. Discharge Current |
10A |
|
|
Max. Temperature Limit |
75°C |
|
| Weight | Max. 44.0G | |
| Internal Resistance | 60mΩ or less | |
| Operating Temperature |
Charge Discharge |
0 ~ 45°C -20~ 60°C |
| Storage Temperature |
1 month 3 months 1 year |
-20 ~ 60°C -20 ~45°C -20 ~ 20°C |
| Dimension |
(D)18.3 + 0.1/-0.3 mm (H) 65.0 ± 0.2 mm |
|
Applications
Light Electric Vehicle
